CNC Milling Engraving Machine

Benefits of CNC Milling Engraving Machine

1.Higher surface quality and shorter process times with the CNC milling engraving machine

Especially for high machining depths and engravings, which are intended for the lifetime, our engraving machine offers you significantly shorter process times compared to laser machining. The chip volume or material removal per pass is significantly higher here and the process time is reduced accordingly.

2.Innovative machine design leads to increased stability and rigidity

The unique machine design of the CNC milling engraving machineresults in significantly higher rigidity. Only through the increased stability can machining operations with significantly larger chip volumes be performed. This offers you increased flexibility and shorter process times. You achieve better surface qualities and longer tool life due to the rigidity.

3.Better tool life due to minimum quantity lubrication in the engraving machine

The CNC milling engraving machine has an integrated minimum quantity lubrication. This permanently cools the tool and lubricates the cutting process.

4.Automatic tool change during machining

Our CNC engraving machine has an automatic tool change. This allows you to easily store up to 23 machining tools in the tool magazine. If you need another tool during machining, the CNC milling machine automatically changes the tool and continues machining. In addition, the various tool lengths are automatically measured and corrected.

Why Choose us

Excellent Product Quality

Worldwide Famous Machine Parts Advanced CNC Controller Imported Precision Processing Equipment.

Rich Experience In Production

20+ Years Manufacturing Experience Exquisite Production Technology

After-Sales Service

Professional Service Teams 7x24 Hours Online Experienced Engineers

CNC Milling Engraving Machine VS Laser Engraving: The Main Differences

Process
CNC milling engraving machine is a subtractive process that removes material from a surface to create the desired shape. It is typically done with a CNC router machine, which uses a cutting tool to cut away material along predetermined paths to create the desired shape or design. Laser engraving is a non-contact process that uses a focused beam of light to etch a design onto a surface. CNC laser engravers use a computer-controlled laser beam to vaporize the material in a pattern that precisely replicates the programmed design.

Accessories
CNC milling engraving machine are equipped with a range of accessories to keep the machine running efficiently and safely. Common accessories include diamond engraving bit holders, toggle clamps, carbide cutting tools, spindle-mounted dusters, and suction pumps.These accessories help keep the work area clean by removing dust and debris with a spindle-mounted dust shoe and suction pump. Laser engraving machines require additional accessories to enable them to engrave on curved surfaces. These accessories include a rotary attachment, air assist system, exhaust system, and safety goggles.

Design phase
The main difference between CNC milling engraving machine and laser engraving is the type of file required during the design phase. CNC engraving requires a CAD file while laser engraving requires a vector or raster file.

Materials
CNC milling engraving machine is commonly employed on metals, wood, and some plastics, providing a high-precision output that can create unique items. Not only that, CNC engraving can be carried out on various materials such as aluminum, brass, and copper. Laser engraving is a more versatile option for a much wider range of materials. Wood, plastics, glass, anodized aluminum, and certain types of stone can all be engraved with a laser engraving machine.

Precision
The accuracy of CNC milling engraving machine can vary depending on the type of machine and the process used.Standard CNC milling engraving machine can provide an accuracy of about 0.001" to 0.005", which is suitable for most manufacturing applications. The accuracy of laser engraving machines depends largely on the quality of the laser beams and the materials used. High-quality laser beams and specialized materials can help increase the accuracy of the laser engraving process.

How to Choose a Tool For CNC Milling Engraving Machine?

For high-density board or solid wood processing, it is recommended to use a spine knife.

For multi-layer board or plywood processing, double-edged straight groove milling cutter is recommended. For acrylic mirror processing, diamond processing tools are recommended.

For rough processing particle board processing, it is recommended to use multiple milling cutters.

For cork, density board, log, PVC board, acrylic large deep relief processing, single-edged spiral ball end milling cutter is recommended.

For cutting aluminum, it is recommended to use a special milling cutter for single-edged aluminum. Because the single-edge special aluminum milling cutter does not stick to the tool during processing, the speed is high and the efficiency is high.

How to Use The tools of CNC Milling Engraving Machine correctly?

The size of the jacket should be appropriate. Jackets with cross-sections, not round, worn, and tapered in the inner hole must not be selected, otherwise it will cause a sensation in the handle and fail to make aspirations.

The handle should touch the jacket gently, and the handle should be pierced firmly into the jacket and tightened. If the jacket has been used for a long time, the inner hole is deformed, it is necessary to replace the jacket immediately.

Always check the patience of the tool. If you use it bluntly, please replace it immediately. If you continue to use it, it will not only perform poorly, but it will also cause the knife to break.

When using woodworking CNC engraving machine, pay attention to that the thickness of the processed material cannot exceed the thickness that the cutting edge can cut, otherwise the knife will be broken or the engraving effect will be unsatisfactory.

For the cutting of different materials, it is necessary to select different tools and adjust the cutting speed reasonably.

During the working process of the engraving machine, the high-speed rotating knives are very sharp. Pay attention to the body, clothes and hair not close to the objects in the work to prevent accidents.

Our Company

202105141044425960041e701e4829a416cbf4b64ab781

Our Certificate of Honor

2021051115430179077f84d23a4ef7b036232c982610f7

20210709150027ac3cad87121d4f5e8036639016817d63

FAQ

Q: Can a CNC router engrave ?

A: Almost any CNC machine can be used as an engraving machine, whether that's a CNC Router or a desktop CNC machine, although there are a few features that can make a particular machine more suitable for engraving. Ideally, a CNC machine used for engraving would include a high-speed spindle.

Q: How does a CNC engraver work ?

A: CCNC engraving is a subtractive process that removes material from a surface to create the desired shape. It is typically done with a CNC (Computer Numerical Control) router machine, which uses a cutting tool to cut away material along predetermined paths to create the desired shape or design.

Q: What are the limitations of CNC milling ?

A: The general limitations of CNC Milling are prototype size, axis movement, and drill bit size. The size and shape limitations will vary by the machine used.

Q: Can a CNC machine engrave acrylic ?

A: CNC acrylic engraving is the process of adding a design, symbol, artwork or marking onto an acrylic product. The automated equipment can engrave something quickly and accurately, so it will look identical each time it is done.

Q: Can a CNC machine engrave stone ?

A: CNC machine you are able to carve and engrave stones such as granite, marble, slate, soapstone and more.

Q: Can you engrave with a milling machine ?

A: This machine can perform drilling, milling, grinding, and tapping along with engraving. This machine is operated at high speed and possesses high cutting ability and machining accuracy. An engraving and milling machine is used to process metals of HRC40 hardness and below.

Q: Can a CNC machine engrave wood ?

A: Though laser engraving might also have been an option to engrave the messages on these coasters, I liked the more natural appearance and depth provided by CNC engraving. The cutting tool was basically shaped like a cone; the deeper that bit goes into the wood, the wider the line.

Q: Which is better CNC or laser engraver ?

A: Assuming everything is only 2D cuts, meaning no cuts that are only part way through the material, a laser will be faster for thin materials or more detailed cuts that might require a very small cutter in the CNC. The CNC will be faster, even factoring in setup, for thicker, less detailed cuts.

Q: Which operation Cannot be performed by CNC milling ?

A: The basic operation of CNC machines are milling, turning, grinding, routing, drilling, etc. Hence, we can clearly see that welding is a joining process that is not done by CNC machines.

Q: Can a CNC machine engrave metal ?

A: Anything can be engraved on metal parts, but it is a secondary process that happens after machining, so it adds to the manufacturing time and costs. You only want to engrave information that's necessary. The two most common ways to engrave metal parts are laser engraving, and CNC engraving.

Q: What is the best CNC bit for acrylic engraving ?

A: 0-flute bits are the go-to bits for all things acrylic with CNC routers. If you haven't created LED-lit acrylic projects, it's definitely time. You are getting a 1/8" diameter O flute bits to tackle those detailed Acrylic signs you'll be making.

Q: Can you cut plexiglass with a CNC machine ?

A: Thanks to its precise manufacturing methods, CNC machining can cut acrylic with just the right amount of force to avoid irreversible damage, quickly and effectively producing acrylic components with accurate shapes and sizes.

Q: Do you need a computer for an engraving machine ?

A: To get started with your laser machine, you'll also need a computer, a graphics software program, an exhaust setup, and any machine accessories you choose.

Q: Can a CNC machine cut rock ?

A: CNC stone cutting can be used on any type of stone, but it is most commonly used for: Limestone–This natural stone is created beneath water bodies over millions of years.

Q: Is CNC machining stressful ?

A: CNC work can be rewarding and challenging, but it also comes with its share of stress and fatigue.

Q: Is CNC machine difficult ?

A: You should expect it to take over 3 years of hard work to master but it can take just a few hours of easy tutorials to create basic parts. Like most skills, CNC machining is a skill that is built upon through experience and trial and error.

Q: Is CNC machining wasteful ?

A: CNC machining is a versatile and precise process that can create various shapes and parts from different materials. However, it also generates material waste and scrap, which can affect the quality, cost, and sustainability of your production.

Q: What is the best wood for CNC engraving ?

A: Cedar—The most used wood for CNC projects, this wood has a nice reddish-brown color. Some wood can have a lot of knots, though. Cypress—This wood also has knots and is not as strong as cedar. Pine—A lighter color and weight wood, pine offers shrink resistance.

Q: Is CNC cheaper than laser ?

A: One of the biggest advantages CNC cutting has is that it is relatively low-cost, especially when compared to laser cutting. The price is why CNC machining has been so popular in a number of different industries for such a long time.

Q: How thick of material can a CNC machine cut ?

A: The effective cutting depth is usually 1/2″. Quarter inch diameter bits are good for cutting thicker materials, like wood, and removing more material per pass. The effective cutting depth is usually 1″. However, for inner shapes and holes it will have less detail than smaller bits.
